FULLER
Kit baleros Fuller K-3339
Arandela eng. aux.
Fuller
4301842
Numero de parte | Descripción | Cantidad |
14750 | SNAP RING | 1 |
14897 | SPRING | 3 |
15918 | SPRING, POS FINDER | 3 |
16980 | SNAP RING | 1 |
4300902-BOX | TAPERED ROLLER BRG | 1 |
4301254 | SNAP RING | 1 |
4301851-BOX | BEARING | 4 |
4302082 | SNAP RING | 2 |
4303424 | SNAP RING | 1 |
4304317 | CLUTCH, SLIDING | 1 |
4308397 | MAIN CASE COUNTERSHAFT BEARING – FRONT | 2 |
4308398 | MAIN CASE COUNTERSHAFT BEARING – REA | 2 |
4308403 | REVERSE GEAR IDLER SHAFT BEARING | 2 |
5556503-BOX | BEARING | 1 |
5566510-BOX | BEARING | 1 |
71205 | SEALANT | 1 |
81504 | BALL BEARING | 1 |
84006 | CONNECTOR, STR | 2 |
85003 | CONNECTOR, ELL | 1 |
K-2805 | SHIM KIT | 1 |
K-2918 | OIL SEAL KIT ELEC. COVER | 1 |
K-3288 | GASKET KIT | 1 |
K-3341 | O-RING KIT | 1 |
L-1680 | LETTER, INSTRUCTION | 1 |
L-3887 | LETTER, INSTRUCTION | 1 |
L-3987 | LETTER, INSTRUCTION | 1 |
S-1659 | INPUT SHAFT ASSY | 1 |
